Bmc:
roadmachine
the one-bike collection - re-imagined
meet the roadmachine, but not as you once knew it. Spliced with yet more speed and less weight, this is the latest iteration of the bike that truly does it all. Rooted in endurance, we’ve revised the frame and added more compliance-boosting attributes to make this bike your all-time favourite roadmate. As our highest performing all-rounder, it’s designed to go the distance with resolve. After all, what use is a road without the roadmachine?
Concept
the one-bike collection - re-imagined
roadmachine’s renowned compliance and versatility blends with the performance dna of our world-tour winning bikes and lets you ride further and faster.
Smoother
the endurance-tuned carbon layup has been developed to enable frame, fork, and seatpost to work as a system and deliver an incredibly plush and balanced riding feel on varying road bike terrain.
The perfect fit for every rider
a carefully selected geometry progression across frame sizes and a broad collection of integrated cockpit system stem dimensions enable the perfect fit for every rider. The finetuned setup delivers a super-clean look and optimum performance.
Faster
the roadmachine boasts a lightweight frame and paramount power transfer. Its performance- oriented dna makes it an ultra-efficient ride on a wide range of terrain.
Sleekest
the integrated cockpit system makes the new roadmachine the most integrated endurance road bike in the game. The stealth cable routing creates a uniquely clean look and improved aerodynamics.
Frameset
frame roadmachine premium carbon frame, tcc endurance
fork roadmachine premium carbon fork, tcc endurance
seatpost roadmachine premium carbon “d” compliance seatpost
frame technology tuned compliance concept (tcc) endurance
sizes 6 sizes: 47 / 51 / 54 / 56 / 58 / 61
frame weight 895g (54cm)**
fork weight 410g (uncut)
seatpost weight 160g (uncut)
integration
frame dti internal cable management
downtube integrated chain catcher
integrated seat clamp
brake integrated front brake mounting hardware
technical details
frame 12 x 142mm thru-axle (shimano standard)
fork 12 x 100mm thru-axle (shimano standard)
disc-specific
seatpost 15mm offset
bottom bracket pf86
brakes flatmount 160/140 (f&r)***
drivetrain braze-on, removable front derailleur mount
replaceable rear derailleur hanger
tires 30mm maximum width (28mm w/ fender)****
misc.
**average sample weight with hardware
***proprietary icf01 flatmount adapter (f) / Shimano flatmount adapter (r)
****tire dimensions based on measured tire width
roadmachine 02 two
- roadmachine, pf86 bottom bracket, flat mount, 12x142mm thru-axle
- premium carbon, tcc endurance
- 47 / 51 / 54 / 56 / 58 / 61
- roadmachine premium carbon, tcc endurance, flat mount, 12x100mm thru-axle
- 2x11
- shimano ultegra, 50-34t
- shimano ultegra, 11-32t
- shimano ultegra
- shimano ultegra
- shimano ultegra
- shimano ultegra, hydraulic
- shimano ultegra, sm-rt800 rotors (160 /140)
- bmc rab 02, ergo top shape, compact bend
- bmc rsm01, w/ computer and camera mount
- roadmachine d-shape carbon, 15mm offset
- selle royal 2075 hrn
- dt swiss e 1850 spline db 23, thru axle
- dt swiss e 1850 spline db 23
- vittoria rubino, 28mm
- super red
note tubeless ready (rim strip installed, valves included)
